Kingspan KS1000RT Roof Tile
KS1000 RT looks like a traditional tiled roof but it is a modern Kingspan insulated panel with a shaped exterior that performs better than any tiling system.
Description
The insulation is built-in and can be used for any domestic or commercial building with a roof pitch of 12° or more after deflection. The traditional look hides a sophisticated system that is easy to construct and complies with all contemporary building standards.
Additional information
| Lengths | Standard: 2.1m – 11.5m |
|---|
| Dimensions, Weight & Thermal Performance | ||||
|---|---|---|---|---|
| Core Thickness (mm) | 45 | 60 | 80 | 100 |
| Overall Thickness (mm) | 85 | 100 | 120 | 140 |
| U-value (W/m²K) | 0.45 | 0.33 | 0.25 | 0.20 |
| Weight (kg/m²) 0.5 Steel/0.4 Steel | 10.7 | 11.3 | 12.2 | 13.1 |
| Datasheet |
| KS1000RW Rood Tile |
 |
