Joris Ide JI Onduroof 1000 Roof Panel

JI Onduroof 1000 is an insulated roof panel suitable for pitched roofs. The sandwich panel consists of an outer sheet with a corrugated profile, a polyisocyanurate (PIR) foam core without harmful CFC-HCFC compounds, and a lightly ribbed inner sheet.

Description

The outer sheet has the aesthetic advantages of a traditional corrugated sheet and is therefore an ideal solution for renovation and new construction projects in both the industrial and agricultural sectors.

Dimensions
Length: Min. 2500.0mm/ max. 20500.0mm
Width: Max. 1000.0mm

Specifications
Thickness (mm)Weight (kg/m2)U (W/m2K)R (m2.K/W)
40.011.110.382.63
60.011.860.293.45
80.012.620.234.35
120.014.130.156.67



Brochure Brochure Technical Datasheet
Guide Handling & Storage JI Onduroof PIR Panels Brochure JI Onduroof 1000
Brochure Brochure Datasheet
